JINGLING 8" Inch Diamond Grinding Disc 3000 Grit Flat Lap Disk Lapping Plate Sanding Pads Lapidary Tools for Stone Pottery Faceting Machine
Product details
| Management number | 250159435 | Release Date | 2026/09/17 | List Price | US$6.00 | Model Number | 250159435 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
JINGLING 8 inch 200 mm Diamond Grinding Disc Coated Flat Lap Disk Wheel Grit 3000 Super Fine Product Name: 8 inch diamond grinding disc, diamond grinding wheels Product Specification: Outside diameter: 8" inch (200mm) Arbor hole: 1/2" (12.7mm) Thickness: 1.1mm Grit: 3000 Grit type: Super Fine Recommended speed:1400-2800RMP Diamond coating Density : Perfectly high Diamond coating surface area : almost 95%, only one side is coated diamond Wet use recommended Suitable to grinding gemstone, jewelry, glass, rock, etc. These diamond discs are one of the finest discs manufactured for hobby, lapidary, glass applications The diamond flat lap wheels have a high density quality diamond coating The diamond sanding pads are absolutely flat and parallel to meet the most exacting faceting requirements When used as part of a multi-stage grinding and polishing process it's easy to create smooth finished edges with a professional look Quick Tips 1. Recommended for rough and fine grinding on faceting material plus general lapidary grinding when precision is required 2. All our flat laps wheels have a 1/2" arbor hole and are intended to be mechanically clamped to a Master Lap 3. The lapping plate is made with 1mm thick steel plate that has been machined true and flat. The diamond lapping plate is stiff enough to be used as is, but we recommend with the use of Aluminum Master Lap Also Available in Grits 60, 80, 100, 120, 150, 180, 240, 320, 400, 500, 600, 800,1000, 1200, 1500, 1800, 2000, 3000
- Suitable to grinding gemstone,jewelry,glass,pottery,ceramics,etc.Especially great for jewellery lapidary making
- Arbor hole of lapidary wheel is 1/2 inch, suitable used for flat lapidary machine, faceting machine, lapidary grinder
- The diamond grinding wheels are one of the finest grinding disc manufactured for hobby, lapidary, glass, pottery applications
- The diamond lapping plate is flat and parallel to meet the most exacting faceting requirements,fully seamless fit in the flat lap machine
- Outside diameter: 8" inch(200mm); Thickness: 1.1mm; Grit: 3000; Grit Type: Fine-; Diamond sanding pad is one side diamond coated
| ASIN | B09V7F7R58 |
|---|---|
| Model | MP-YX200-3000# |
| Grit Type | Super Fine |
| Brand Name | JINGLING |
| Unit Count | 1 Count |
| Grit Number | 3000 |
| Part Number | MP-YX200-3000# |
| Manufacturer | JINGLING |
| Item Diameter | 20 centimeters |
| Material Type | Carbon Steel, Diamond |
| Item Thickness | 1.1 millimeters |
| Item Dimensions | 8 x 8 x 0.04 inches |
| Number of Items | 1 |
| Number of Packs | 1 |
| Construction Type | Coated |
| Compatible Devices | Faceting Machine, Flat lap machine, Flat lapidary machine, Lapidary grinder |
| Grit Material Type | Diamond |
| Compatible Material | Gemstone, Jewelry, Glass, Pottery, Ceramics |
| Item Dimensions L x W | 8"L x 8"W |
| Maximum Rotational Speed | 2800 rpm |
| Industry Standard Identifier | ISO 6344-2:1997 |
| Recommended Uses For Product | Grinding |
